https://trivenipackaging.com/products-details/belgun-depositor/ Belgun Depositor / Filling Machine
The Beldos Belgun is a volumetric stainless steel depositor operated through a handgun nozzle only. Optional attachments cover depositing, injection, layering and decoration. It stands on a low, fixed-height frame so the hopper is easy to fill, and runs on compressed air with no electrical connection.
Key features
- Dosing principle: volumetric piston
- Operation: handgun nozzle only
- Attachments: optional, for depositing, injection, layering, decoration
- Frame: low, fixed height for easy hopper filling
- Drive: pneumatic, no electricity required
- Construction: stainless steel
Applications
For pastry and dessert teams where the operator places each portion by hand. Typical products: cake batter, muffins, jam, jelly, fruit filling, cream, mousse, meringue, yoghurt, soup, sauces, mashed potato, minced meat and salads. Also injects Berliners and profiteroles.
Technical specifications
| Belgun 275 | Belgun 670 | |
|---|---|---|
| Deposit range | 5 to 275 ml | 5 to 670 ml |
| Speed | Up to 120 deposits/min | Up to 120 deposits/min |
| Hopper | 18, 25 or 60 l | 18, 25 or 60 l |
| Air consumption | 29 l/min at 30 deposits/min | 121 l/min at 30 deposits/min |
| Air pressure | 7 bar / 102 PSI | 7 bar / 102 PSI |
| Electricity | Not required | Not required |
| Material | Stainless steel | Stainless steel |
Brochure and detailed technical data sheet: available on request. Contact our team or use Get a Quote below.
